Towing with the 2026 Jeep Wrangler: What You Need to Know for Your Next Trip

Published on May 21, 2026 by DDM Devs

Our team believes that a vehicle is more than just a way to get around; it is a legacy of freedom that has been passed down through generations. For families in Newcastle, that legacy often involves weekend trips to Lake Stanley Draper to launch a boat or head out for a day of fishing. The 2026 Jeep Wrangler continues this tradition of rugged reliability, offering the mechanical strength required to bring your gear along for the ride. We take pride in our deep roots here in the community, and we focus on building lasting relationships by ensuring every driver finds the right configuration for their specific lifestyle.

Before you set out on your next excursion, it is essential to understand how the latest updates to this iconic SUV affect your towing experience. Whether you are interested in our current selection of certified pre-owned models or a brand-new factory order, knowing the limits of your equipment is the first step toward a safe journey. We invite you to (405) 265-1400 to discuss your specific needs with our knowledgeable staff. If you are just starting your research, you can also prequalify online to see which trims fit your budget. When you are ready to see the hardware in person, our showroom address is a simple destination for anyone in the Yukon area.

Section 01

Maximum Towing Capacity and Chassis Requirements


Does every version of the new SUV offer the same pulling power? The answer depends entirely on the chassis and the rear axle configuration you select. For the 2026 model year, the Wrangler provides a maximum towing capacity of 5,000 lbs on four-door models, provided they are equipped with the heavy-duty Dana 44 full-float rear axle. This specific axle design is a significant advantage for those who trailer frequently, as it transfers the vehicle's weight to the wheel hub rather than the axle shaft itself, increasing durability under heavy loads.

5,000
lbs — 4-Door Max
With Dana 44 full-float rear axle on Rubicon & Willys trims
2,000
lbs — 2-Door Max
Shorter wheelbase limits capacity regardless of trim or engine
392
3,500
lbs — Moab 392
Performance-tuned suspension prioritizes off-road traversal over max tow
Jeep Wrangler towing a boat trailer on a highway near a lake
Pricing — MSRP and destination charges
FeatureWillysSportRubiconMoab 392SaharaSport S
Starting MSRP$79,995

Lowest starting MSRP: Moab 392 at $79,995

If you prefer the classic two-door body style, the maximum capacity is limited to 2,000 lbs regardless of the trim level. This difference is primarily due to the shorter wheelbase, which impacts stability when a trailer is attached. For those looking for the ultimate performance flagship, the Moab 392 carries a starting MSRP of $79,995 and is rated to tow 3,500 lbs. While it features incredible power, its suspension is tuned more for high-speed off-road traversal than maximum heavy-duty towing. For shoppers who need high capacity but prefer a different budget, we have all used vehicles in stock to compare, including several used Grand Cherokees that might offer the utility you require. You can browse our used SUV inventory to see the full range of towing-capable options currently available on our lot.

Section 02

Deciding Between the 2.0L Turbo and 3.6L V6 for Towing

A common misconception among many of our customers is that more cylinders always lead to better towing performance. In the case of the 2026 Jeep Wrangler, the 2.0L Turbocharged I-4 engine actually provides more torque at lower engine speeds, delivering 295 lb-ft of torque compared to the 260 lb-ft found in the 3.6L Pentastar® V6. This low-end torque is helpful for getting a heavy trailer moving from a complete stop. However, the 3.6L V6 remains a favorite for its linear power delivery and is the only choice for those who still want a manual transmission.

Torque Comparison — lb-ft
2.0L Turbo I-4295 lb-ft
3.6L Pentastar® V6260 lb-ft
6.4L HEMI® V8 (Moab 392)470 lb-ft
Best for Towing
2.0L Turbocharged I-4
295
lb-ft Torque
270
Horsepower

Delivers peak torque at lower RPMs — ideal for pulling heavy loads from a standstill. eTorque mild-hybrid system available for even smoother response.

Manual Available
3.6L Pentastar® V6
260
lb-ft Torque
285
Horsepower

Linear power delivery makes it a favorite for daily drivers. The only option compatible with the 6-speed manual transmission — perfect for driving purists.

V8 engine power
Moab 392 Exclusive
6.4L HEMI® V8
470
lb-ft Torque
470
Horsepower

For those who prioritize raw strength, the Moab 392 trim features this V8 that pulls like a locomotive. Available exclusively in four-door configuration. If you are unsure which powertrain aligns with your goals, please contact us to schedule a consultation. We can walk you through all new vehicles in our current lineup.

Engine & Performance — Powertrain specifications across trim levels
Feature Willys Sport Rubicon Moab 392 Sahara Sport S
Engine 6.4L HEMI® V8
Jeep Wrangler with trailer hitch hitched to a trailer
Section 03

Factory Trailering Features and Hitch Configurations

One of the first things I show buyers during a walk-around is the integrated towing hardware that makes the 2026 Jeep Wrangler ready for the road. Most models come equipped with a Class II hitch receiver and both 4-pin and 7-pin wiring harnesses, which allow you to connect a wide variety of trailer types without needing aftermarket adapters.

Class II Hitch Receiver
Factory-installed on most models, rated for up to 5,000 lbs on properly equipped four-door trims. No aftermarket fab required.
7-Pin Wiring Harness
Both 4-pin and 7-pin connectors are included, supporting trailer brake controllers, auxiliary power, and reverse lights out of the box.
Integrated Aux Switch Bank
Control trailer accessories or additional exterior lighting directly from the cabin. Eliminates dashboard clutter from aftermarket switch panels.
Weight-Distributing Hitch
Recommended for loads approaching 5,000 lbs. Levels the vehicle and trailer, improving steering control and braking stability at highway speed.
Tongue Weight Control
Proper tongue weight (10–15% of total trailer weight) keeps front wheels planted. Our team helps you select the right setup for your specific trailer.
Mopar® Accessories Ready
Genuine factory accessories — ball mounts, hitch pins, wiring adapters — designed specifically for your Wrangler, available through our parts department.
Close-up of a trailer hitch receiver and wiring harness

Additionally, the inclusion of an integrated auxiliary switch bank is a practical touch for those who want to control trailer accessories or additional exterior lighting directly from the cabin.

When you are approaching the 5,000 lbs maximum capacity on a Rubicon or Willys model, we often recommend using a weight-distributing hitch. This hardware helps level the vehicle and the trailer, which improves steering control and braking stability on the highway.

If you are ready to move forward with a purchase, you can apply for financing through our secure portal. You can also check our directions and hours to plan a visit to see these features in person.

Section 04

Mastering Flat Towing and RV Integration

Residents in El Reno often enjoy a rural lifestyle that includes long-distance travel, making the Wrangler a premier choice for "dinghy" towing behind a motorhome. Because the vehicle features a robust transfer case with a true neutral setting, it can be flat towed with all four wheels on the ground without damaging the transmission. This is a rare capability in the modern SUV market and one of the primary reasons the Jeep Wrangler JL remains the most popular choice for RV enthusiasts across the country.

Command-Trac® Part-Time 4×4
Rock-Trac® Full-Time
True Neutral Position
Flat Tow Certified
Motorhome towing a Jeep Wrangler on a scenic highway
Jeep Wrangler on an off-road trail behind an RV campsite
1

Install Aftermarket Base Plate Kit

Mount a base plate to the frame to connect to your RV's tow bar system. This is vehicle-specific hardware that must be properly torqued to spec.

2

Place Transfer Case in Neutral

Both Command-Trac® and Rock-Trac® systems provide the necessary neutral position, allowing all four wheels to spin freely without drivetrain damage.

3

Connect Tow Bar & Safety Chains

Attach to your motorhome's tow bar receiver, hook safety chains in a crossed pattern below the hitch, and connect the supplemental braking system.

4

Connect Lighting & Verify All Systems

Wire trailer lighting (brake, turn, running), verify the steering is unlocked, and do a walk-around before pulling out. Consult your owner's manual for specific steps.

To set up your vehicle for flat towing, you will need to install an aftermarket base plate kit on the frame to connect to your RV's tow bar. If you are considering trading in your current vehicle to upgrade to a tow-ready SUV, we encourage you to use our trade valuation tool to get an accurate estimate of its worth. You can also explore our new vehicle specials to find a great value on new Wranglers that are ready for your next cross-country trip.

Section 05

Advanced Safety Tech for Confident Trailering


Safety is a top priority for our team, and the 2026 Jeep Wrangler includes several structural and technological updates to protect you while trailering. For models built after October 2025, reinforcements were added to the frame rail to improve driver occupant protection. When it comes to active safety, the Trailer Sway Control system is standard, using electronic stability sensors to detect trailer oscillation and automatically applying brake pressure to individual wheels to bring the load back under control.

Maintaining these systems is vital for long-term reliability. We recommend scheduling regular check-ups with our service department to ensure your sensors and brakes are in peak condition. You can also view used vehicle specials if you are looking for a pre-owned model with these technologies already included.

Trailer Sway Control
Electronic stability sensors detect trailer oscillation and automatically apply selective brake pressure to individual wheels to restore control.
ParkView Back-Up Camera
Dynamic grid lines make hitch alignment straightforward. Eliminates the guesswork of backing up to a ball mount or maneuvering in tight spaces.
Blind Spot Detection
Available system helps monitor the full length of your trailer, alerting you to vehicles in zones that mirrors alone cannot adequately cover during lane changes.
Full Speed FCW+
Full Speed Forward Collision Warning Plus assists with emergency braking at all speeds — critical when hauling a loaded trailer with extended stopping distances.
Frame Rail Reinforcement
Models built after October 2025 include added frame rail reinforcements for improved driver occupant protection — a significant structural upgrade.
Trailer Brake Controller Ready
7-pin connector supports in-cabin brake controllers, allowing proportional braking on trailers with electric brakes for dramatically shorter stopping distances.
TOP
SAFETY
PICK+
IIHS Award

All 2026 Jeep Wrangler trims — Willys, Sport, Rubicon, Moab 392, Sahara, and Sport S — carry the IIHS TOP SAFETY PICK+ designation, the highest award available from the Insurance Institute for Highway Safety. This rating applies across the entire model lineup, meaning your choice of trim does not compromise crash protection. Headlights vary by trim and option (rated "M"), and optional blind spot detection is available across trims.

Note: NHTSA 5-star overall rating data for 2026 model year was not available at time of publication. IIHS front crash prevention — pedestrian (day) is listed as "Not available."

Safety & Driver Assistance — Safety ratings and driver assistance systems
FeatureWillysSportRubiconMoab 392SaharaSport S
IIHS RatingTOP SAFETY PICK+TOP SAFETY PICK+TOP SAFETY PICK+TOP SAFETY PICK+TOP SAFETY PICK+TOP SAFETY PICK+

Standard across all trims

NHTSA RatingNot found for 2026 Jeep Wrangler — no 2026 model-year NHTSA 5-star overall rating page data was located.

HeadlightsOverall IIHS rating shown as "M" — headlights vary by trim and option package.

Front Crash PreventionIIHS pedestrian (day) front crash prevention is listed as "Not available" for this model.

Available Safety FeaturesOptional blind spot detection is listed as an available feature across all trims.

Section 06

Frequently Asked Questions About Wrangler Towing


Jeep Wrangler parked at a trailhead ready to tow
  • Yes, the two-door model is rated for 2,000 lbs regardless of the engine or axle chosen. This is due to the shorter wheelbase, which cannot provide the same level of stability as the four-door chassis when handling the leverage of a heavy trailer.

  • While not required for lighter loads, we generally recommend a weight-distributing hitch for trailers that exceed 3,500 lbs. This helps distribute the tongue weight across all axles, keeping the front wheels planted for better steering and braking performance.

  • The Wrangler 4xe has a maximum towing capacity of 3,500 lbs. At the same time, it offers excellent torque, the added weight of the battery system and the specific suspension tuning result in a lower rating than the four-door gas models equipped with the full-float axle.

  • The full-float design is engineered so that the vehicle's weight is supported by the axle housing rather than the internal axle shafts. This allows for a higher maximum towing capacity of 5,000 lbs on properly equipped Rubicon and Willys models.

  • If you need a new ball mount, wiring adapter, or hitch pin, our parts department stocks genuine Mopar accessories designed specifically for your vehicle. We also have all used trucks and used vehicles under $30k that come with various towing configurations already installed.

Section 07

Start Your Next Journey at Joe Cooper Chrysler Dodge Jeep Ram of Yukon

Our team is here to help you navigate every technical detail of your next vehicle purchase, ensuring you have the power and safety you need for the road ahead. Whether you are looking for a heavy-duty hauler like our new Ram trucks or a versatile SUV from our used inventory, we focus on providing an honest and professional experience.

Give us a quick call or stop by our Yukon showroom to begin your adventure today.
